RF Logarithmic Detector Module 1MHz-8GHz
68.99 €
🆓 FREE SHIPPING with tracking number!
✅ No Import Taxes on delivery!
🏷️ Condition: New
🚚 Ships from: HK Warehouse – Hong Kong (China)
↩️ Easy Returns within 30 days of receipt
🙋 Any questions? Contact Jake
Achieve precise RF power measurement with this compact AD8318 logarithmic detector module, operating from 1MHz to 8GHz with accuracy up to 6GHz. Powered by a 5V DC supply and consuming approximately 80mA, it features a 50-ohm input impedance suitable for sine wave and pulse signals (default to mean detection), with an input power range from -65dBm to +20dBm and a dynamic range over 70dB. The output voltage varies from 0.5V to 2.1V, with a linear dB response and a response time of about 10 nanoseconds. Its 32mm x 24mm x 7mm design, integrated metal shield, SMA connectors, and operating temperature of -25°C to +75°C make it ideal for transmitter power and receiver strength testing.
In stock
This Precise RF Logarithmic Detector Module
Experience reliable and accurate RF measurements with this high-performance logarithmic detector module. Designed to operate within 1MHz to 8GHz, it maintains exceptional accuracy up to 6GHz, ideal for transmitter power testing, receiver strength measurement, and RF analysis. Its compact size of 32mm by 24mm with a 7mm height makes it easy to integrate into your projects. The sleek matte black PCB, featuring white silkscreen labels and gold SMA connectors, reflects a professional, modern aesthetic. Built with durability in mind, it includes an integrated metallic shield cover that ensures electromagnetic shielding for optimal signal integrity. This essential device guarantees precise readings in a user-friendly package, boosting your confidence in every RF application.
Keys features of the RF logarithmic detector module
- Operates on a 5V DC supply with 80mA current, ensuring efficient operation within typical RF systems.
- Measures RF signals from -65dBm up to +20dBm across 1MHz to 8GHz, with accurate performance up to 6GHz for versatile uses.
- Has an input impedance of 50 ohms, compatible with sine wave and pulse signals (default to mean detection, modifications needed for pulse detection).
- Provides an output voltage range from 0.5V to 2.1V, with a linear dB response and a typical logarithmic slope of -25mV/dB for precise amplitude measurement.
- Built with high-quality surface-mount components and an integrated metallic shield for electromagnetic compatibility and durability.
- Dimensions of 32mm x 24mm x 7mm, light at just 10 grams, with a response time of approximately 10 nanoseconds ideal for RF burst detection above 45MHz.
Get your RF detector module today—perfect for high-frequency RF testing
Imagine seamlessly integrating this RF logarithmic detector into your measurement setup, confidently reading RF power levels across a broad frequency range. Whether refining transmitter performance or analyzing receiver strength, this module offers precision and reliability. Its sleek design and robust construction ensure consistent results and easy installation. Make this essential RF component yours now to elevate your projects and experiments effortlessly. Trust in its technical excellence—your RF testing precision starts here!
This RF logarithmic detector module is the perfect choice for professionals requiring accurate RF power measurement and signal analysis. Its advanced features, compact size, and durable build empower you to achieve reliable, high-precision results in your RF applications. Invest today and take your RF testing capabilities to the next level.
