High-Speed AD9226 12-Bit ADC Module
Price range: 50.99 € through 71.99 €
🆓 FREE SHIPPING with tracking number!
✅ No Import Taxes on delivery!
🏷️ Condition: New
🚚 Ships from: HK Warehouse – Hong Kong (China)
↩️ Easy Returns within 30 days of receipt
🙋 Any questions? Contact Jake
Experience precise high-speed signal acquisition with this compact 54mm x 37mm x 23mm black PCB module featuring a 12-bit resolution and a maximum sampling rate of 65MSPS. Powered by a stable 5V DC supply (range 4.75V–5.25V), it boasts an internal 2V reference, 320MHz analog bandwidth, and a 13-bit parallel SPI communication protocol at 3.3V. With a 50Ω input impedance via SMA or XH2.54 interface, it integrates the ADI AD9226 ADC utilizing differential pipeline architecture with sample-and-hold and error correction, ensuring accurate data output. Weighing approximately 16g, this high-speed ADC module is ideal for FPGA platforms, supporting Verilog routines and industrial-grade applications.
This high-speed AD9226 ADC module for precise data acquisition
Experience the power of this sleek, black PCB module designed for high-performance signal conversion. With its compact dimensions of 54mm by 37mm by 23mm and a weight of just 16 grams, this module offers an ideal balance of size and capability. The bold black surface provides a modern aesthetic, contrasted by gold-colored SMA connectors and crisp white silkscreen labels that indicate connection points and settings. Its carefully arranged surface-mounted resistors and capacitors showcase meticulous engineering. The module’s high-tech appearance emphasizes its professional-grade performance—perfect for integrating into FPGA development projects. Let this module elevate your high-speed data acquisition setups with its reliable, precise, and visually striking design, inspiring confidence in your technical endeavors.
Keys features of the AD9226 high-speed ADC module
- 12-bit resolution with a maximum sampling rate of 65MSPS, ensuring high-precision digital conversion for demanding applications.
- Powered by a stable 5V DC supply, with an input voltage range of 4.75V to 5.25V, supporting consistent operation across various setups.
- Built-in internal 2V reference voltage, offering stable, accurate analog-to-digital conversion with an analog bandwidth of 320MHz for high-frequency signals.
- Compatible with FPGA development platforms, supporting routines in Verilog, with a 13-bit parallel SPI communication protocol at 3.3V level for seamless integration.
- Includes an OTR overflow pin that signals input voltage exceeding ±5V limits, ensuring safety and reliable data conversion.
- Features differential pipeline architecture with integrated sample-and-hold and error correction logic for maximum accuracy and no missed codes.
This AD9226 ADC module is a smart choice for your projects—buy now and enhance your data acquisition system
Imagine confidently integrating this high-performance ADC module into your FPGA setup or testing environment. Its precise analog-to-digital conversion capabilities, robust design, and compact form factor ensure you achieve reliable, high-speed data results. Whether you're developing advanced signal processing systems or performing critical measurements, this module provides the technical excellence you need. Once installed, you’ll appreciate its ease of use, stability, and unmatched performance. Don't miss out on upgrading your collection with this top-tier component—invest today and experience the difference in your projects’ precision and speed.
