This DIY Mini Digital Oscilloscope Kit by Gaqqee
Transform your electronics projects with this this DIY Mini Digital Oscilloscope Kit, featuring the powerful STC8K8A microcontroller. Perfect for electronics enthusiasts, this kit offers a hands-on soldering experience and helps you understand signal behavior visually. Its compact size (57x35mm) makes it portable and easy to handle, while its versatile functions suit both beginners and experienced hobbyists. The kit includes all necessary components for assembly, allowing you to refine your skills in soldering and electronics measurement. With adjustable trigger modes, waveform generator, and EEPROM storage, this oscilloscope unlocks a new level of insight into electrical signals. Elevate your electronics toolkit today by building your own precision instrument tailored to your projects.
Keys features of the this DIY Mini Digital Oscilloscope Kit
- Features three trigger modes: automatic, normal, and single, enabling flexible measurement scenarios for varied signal types.
- Includes indicator lights to show sampling status and a waveform generator with PWM and sine wave functions for testing and experimentation.
- Supports adjustable trigger slope and level, capturing signals on rising or falling edges, ideal for precise waveform analysis.
- Stores user settings automatically in EEPROM, ensuring your preferences are saved for future measurements without reconfiguration.
- Powered via a common 5V micro USB with a wide voltage range of 0-30V, suitable for many electronic devices and circuits.
- Compact and lightweight design (57x35x30mm), making it easy to use in diverse environments and DIY projects.
Build your own oscilloscope and enhance your skills now
This this DIY Mini Digital Oscilloscope Kit is the perfect starting point for hobbyists eager to learn signal analysis and improve their soldering abilities. By assembling this kit, you gain both a functional instrument and valuable knowledge about electronics. Whether you’re testing circuits, learning about waveforms, or experimenting with signals, this tool supports your growth. Add it to your collection today and enjoy the satisfaction of creating a high-quality, personalized measurement device that adapts to your needs. Take the next step in your electronics journey with confidence!
