Adjustable Signal Generator Module for Circuits
23.99 €
🆓 FREE SHIPPING with tracking number!
✅ No Import Taxes on delivery!
🏷️ Condition: New
🚚 Ships from: HK Warehouse – Hong Kong (China)
↩️ Easy Returns within 30 days of receipt
🙋 Any questions? Contact Jake
This compact adjustable signal generator module produces stable square wave pulses with a frequency range of 0.8Hz to 60Hz (L version) and 50Hz to 6kHz (H version). Featuring a 14mm x 10.5mm x 7.4mm green circuit board, it includes a yellow multi-turn potentiometer for precise frequency adjustment, white silkscreen labels for easy connections, and a 3-pin header for power and signal output. Powered by 5V to 15V DC, it can source or sink up to 200mA current, with an output amplitude roughly matching the input voltage. Perfect for circuit testing, signal generation, and experimental setups for enthusiasts and professionals.
This Adjustable Signal Generator Module for Circuits
Experience the versatility of this compact, green-colored signal generator module designed to produce precise square wave pulses. Its small size—14mm by 10.5mm by 7.4mm—makes it perfect for tight spaces while offering stable performance across a broad frequency range. The built-in multi-turn potentiometer allows smooth, accurate frequency adjustments from 0.8Hz to 60Hz in the low version and 50Hz to 6kHz in the high version. With a straightforward design featuring white silkscreen labels and a bright yellow coaxial connector for frequency adjustment, the device ensures clarity and ease of use. Its lightweight construction at only 1.4g makes it an ideal choice for hobbyists, testers, and professional circuit designers seeking a reliable pulse source.
Keys features of this adjustable signal generator module
- This module provides a wide frequency range, from 0.8Hz to 60Hz in the low version and 50Hz to 6kHz in the high version, ideal for diverse electronic testing and development needs.
- The built-in multi-turn potentiometer allows precise, smooth frequency tuning, ensuring accurate signal generation without complex setup procedures.
- It features a stable output amplitude close to input voltage, with a fixed duty cycle typically ranging from 50% to 65%, suitable for various pulse and signal simulation applications.
- The power supply requirement of DC 5V to 15V, with a minimal no-load current of about 3mA, guarantees easy integration with standard power sources, while supporting output currents up to 200mA.
- Connectivity is streamlined through a 3-pin header (G, D, V) with clear white markings, compatible with TTL logic levels at 5V, perfect for microcontroller interfacing.
- Measuring just 14mm x 10.5mm x 7.4mm and weighing only 1.4g, it is extremely portable and unobtrusive for embedded projects or compact circuit designs.
This versatile signal generator module makes your projects easier—buy now
Imagine having precise control over your circuit signals, simplifying testing and experimentation. This adjustable signal generator module is a dependable companion for engineers, enthusiasts, and students. Its small footprint enables seamless integration into any project, providing stable, reliable square wave pulses. Whether you’re tuning a device, developing a new circuit, or troubleshooting, this device’s ease of use and robust specifications give you peace of mind. Take your electronics work to the next level by adding this efficient, compact module to your toolkit today — unlock new possibilities and ensure your circuits perform flawlessly.
| Color | L 0.8Hz-60Hz, H 50Hz-6Khz |
|---|---|
| Condition | New |
| Warehouse | HK Warehouse – Hong Kong |
